The ribbon coder is not clear how to adjust？

1, check whether the coding machine has been re-adjusted, whether it is due to the equipment re-adjusted resulting in the inability to print properly and clearly, targeted to make adjustments and reinstallation.

2, to exclude the thermal transfer coding machine equipment failure itself, we can start to observe the thermal transfer coding machine print head, to see if the print head is out of the question:.

(1) continuous coding machine: the print head action is not exactly in the centre of the pressure in the rubber roller, the coding machine needs to readjust the position.

(2) intermittent coding machine: silicone pad was damaged, and now the unevenness of the phenomenon. Replace can be.

3, air pressure is not adjusted.

No air pressure or air pressure is too low will lead to unclear printing, such as air pressure is too high will affect the life of the print head, need to be adjusted between 0.45-0.6, can not be higher than 0.6.

4, the print blackness is adjusted too low: print head printing temperature is not enough will also lead to unclear printing.

5, whether the print head resistance adjustment (replacement print head need to adjust the resistance data in the display, not adjusted to affect the life of the print head)
